Hot sale Original ADG509AKR Interface IC SP4T 2 Circuits 450Ohm 300ns 1nA Switch Circuit 10.8V-16.5V Surface Mount 16-SOIC

Product Overview

Presented in 16-SOIC (0.154, 3.90mm Width), this electrical component is convenient for overseas shipping. High reliability is ensured by the advanced packaging method Tube. Surface Mount is where this multiplexer is located. Multiplexer and demultiplexer circuits have a number 4:1. Increasing operating temperature to around -40°C~85°C TA. Totally, there are 16 terminations. A high-quality output is provided by the electrical component's 1 channels. It is safe to turn on and run the electronic component with a 15V voltage supply. A total of 16 pins are injected into the electrical part body. A SP4T switching circuit is used for these analog switches. The circuits in this analogue multiplexer number 2. Using the ADG509 search parameter, you can discover variants of the switch. In this multiplexer, the internal resistance is 450Ohm. For details about the functions of 16 pins, please refer to the datasheets. It is generally not recommended to supply a voltage higher than 16.5V to the switch device in normal circumstances. 10.8V is the lowest voltage the electrical component should receive. For this digital switch to work, 600μA current would suffice. Putting voltage greater than 1.5mA on the multiplexer may cause damage. There is no problem with using dual supply voltage, but it should not exceed 16.5V. With dual power supplies, you should attach at least 10.8V. It is integrated with a DIFFERENTIAL MULTIPLEXER analog IC. The 8 inputs need to be operated in order to work.

Product Features

1 Channels
Switch Circuit: SP4T
600μA Supply Current

Product Applications

ADG509AKR Analog Switches & Multiplexers ICs applications.

· Precision data acquisition

· Battery-powered systems

· Sample-and-hold systems

· Communication systems

· Data Acquisition Systems

· Relay Replacement

· Battery Powered Systems

· Existing multiplexer applications (both fault-protected and nonfault-protected)

· New designs requiring multiplexer functions

· Cellular phones
