Spot sales of CD4024BCN 7-Stage Ripple Carry Binary Counter DIP-14
Manufacturer Product Number
CD4024BCN
Description
CD4024BCN 7-Stage Ripple Carry Binary Counter DIP-14
Package Condition
Tube
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The CD4024BC is a 7-stage ripple-carry binary counter. Buffered outputs are externally available from stages 1 through 7. The counter is reset to its logical “0” stage by a logical “1” on the reset input. The counter is advanced one count on the negative transition of each clock pulse.
Product Features
■ Wide supply voltage range: 3.0V to 15V
■ High noise immunity: 0.45 VDD (typ.)
■ Low power TTL compatibility: Fan out of 2 driving 74L or 1 driving 74LS
■ High speed: 12 MHz (typ.) input pulse rate VDD − VSS = 10V
■ Fully static operation
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-CD4024BCN |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Counters, Dividers | |
| Manufacturer | - |
| Series | 4000B |
| Packaging | Tube |
| Part Status | Obsolete |
| Logic Type | Binary Counter |
| Direction | Up |
| Number of Elements | 1 |
| Number of Bits per Element | 7 |
| Reset | Asynchronous |
| Timing | - |
| Count Rate | 12 MHz |
| Trigger Type | Negative Edge |
| Voltage - Supply | 3 V ~ 15 V |
| Operating Temperature | -55°C ~ 125°C |
| Mounting Type | Through Hole |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Supplier Device Package | 14-MDIP |
| Base Product Number | CD4024 |
Product Photos
For more product information, please download the PDF
