Hot sale Original TOP254PN PMIC IC OFFLINE SWITCH FLYBACK 8DIP Converter Offline Flyback Topology 66kHz 8-PDIP-C

Manufacturer
Manufacturer Product Number
TOP254PN
Description

Original TOP254PN PMIC IC OFFLINE SWITCH FLYBACK 8DIP Converter Offline Flyback Topology 66kHz 8-PDIP-C

Package Condition
Original

Product Overview

This ac to dc converter is embedded in package 8-DIP (0.300, 7.62mm), 7 Leads .The AC/DC power converter is available in Tube .There is a AC/DC converter mounted in the way of Through Hole .For the ac dc converter to perform properly, it should be operated at a temperature of -40°C~150°C TJ °C.In this AC DC converter, the analog IC type is ANALOG CIRCUIT .In total, there are 7 terminations.The ac/dc converter has a total of 8 pins.Through Hole are the recommended mounting method for the ac dc converters.This AC to DC converter belongs to the TOPSwitch®-HX manufacturer family.A total of 1 outputs are to be processed.There is 700V voltage output from it.A high efficiency is achieved when operating at a frequency of 66kHz .It is possible to read the REACH SVHC standard at: No SVHC .An input voltage of 265V is available for powering the AC to DC converter.A coverter produces 20W watts of output power.Using this ACDC converter, it is also possible to identify SEATED_HT CALCULATED .It is possible to use the AC to DC inverter with an input voltage less than 85V V.There is a minimum supply voltage of 85V across the converter.There is 265V maximum supply voltage across the converter.A AC to DC power converter's input voltage (AC) should not exceed 265V .It is capable of working with a minimum supply voltage of 36V volts.

Product Features

Packaged with 8-DIP (0.300, 7.62mm), 7 Leads
With 8 pins

Product Applications

There are a lot of Power Integrations
TOP254PN AC DC Converters applications.

· AC/DC Adaptors/Chargers for E-books

· Adaptors for Portable Media Player

· Adaptors for DSCs

· Set-top boxes

· DVD players

· Records

· Linear Adapter Replacements

· Chargers for cell/cordless phones

· PDAs

· MP3

Product Description

Type

Description

ANSC PART#

ANSC - TOP254PN

Category

Integrated Circuits (ICs)

Power Management (PMIC)

AC DC Converters, Offline Switches

Manufacturer

Power Integrations

Series

TOPSwitch®-HX

Packaging

Tube

Part Status

Active

Output Isolation

Isolated

Internal Switch(s)

Yes

Voltage - Breakdown

700V

Topology

Flyback

Voltage - Supply (Vcc/Vdd)

-

Duty Cycle

78%

Frequency - Switching

66kHz

Power (Watts)

28 W

Fault Protection

Current Limiting, Over Temperature, Over Voltage

Control Features

-

Operating Temperature

-40°C ~ 150°C (TJ)

Package / Case

8-DIP (0.300", 7.62mm), 7 Leads

Supplier Device Package

8-PDIP-C

Mounting Type

Through Hole

Base Product Number

TOP254
