Hot-selling and scarce IRS2104STRPBF HALF-BRIDGE DRIVER IC SOP-8 spot stock

Product Features

• Floating channel designed for bootstrap operation

• Fully operational to +600 V

• Tolerant to negative transient voltage, dV/dt immune

• Gate drive supply range from 10 V to 20 V

• Undervoltage lockout

• 3.3 V, 5 V, and 15 V input logic compatible

• Cross-conduction prevention logic

• Internally set deadtime

• High-side output in phase with input

• Shutdown input turns off both channels

• Matched propagation delay for both channels

• RoHS compliant

Product Specifications

Product Photos

For more product information, please download the PDF

WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
