Hot sale Original AD22100AR SENSOR ANALOG -40C-85C 8SOIC Temperature Sensor Analog and Digital Output 8-SOIC Surface Mount
Manufacturer
Manufacturer Product Number
AD22100AR
Description
Original AD22100AR SENSOR ANALOG -40C-85C 8SOIC Temperature Sensor Analog and Digital Output 8-SOIC Surface Mount
Package Condition
Tube
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
GENERAL DESCRIPTION
The AD22100 is a monolithic temperature sensor with on-chip signal conditioning. It can be operated over the temperature range −50°C to +150°C, making it ideal for use in numerous HVAC, instrumentation, and automotive applications.
The signal conditioning eliminates the need for any trimming, buffering, or linearization circuitry, greatly simplifying the system design and reducing the overall system cost.
The output voltage is proportional to the temperature x the supply voltage (ratiometric). The output swings from 0.25 V at −50°C to +4.75 V at +150°C using a single +5.0 V supply.
FEATURES
200°C temperature span
Accuracy better than ±2% of full scale
Linearity better than ±1% of full scale
Temperature coefficient of 22.5 mV/°C
Output proportional to temperature × V+
Single-supply operation
Reverse voltage protection
Minimal self-heating
High level, low impedance output
APPLICATIONS
HVAC systems
System temperature compensation
Board level temperature sensing
Electronic thermostats
Product Description
| Product Attribute# | Attribute Value |
| ANSC PART# | AD22100AR |
| Category | Sensors, Transducers |
| Temperature Sensors | |
| Analog and Digital Output | |
| Manufacturer | Original |
| Series | - |
| Packaging | Tube |
| Part Status | Obsolete |
| Sensor Type | Analog, Local |
| Sensing Temperature - Local | -40°C ~ 85°C |
| Sensing Temperature - Remote | - |
| Output Type | Analog Voltage |
| Voltage - Supply | 4V ~ 6.5V |
| Resolution | 22.5mV/°C |
| Features | - |
| Accuracy - Highest (Lowest) | ±2°C (±3.7°C) |
| Test Condition | 25°C (-40°C) |
| Operating Temperature | -50°C ~ 150°C |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | AD22100 |
