BOM distribution service electronic components SI7160DP N-Channel 30-V (D-S) MOSFET with Schottky Diode
Manufacturer Product Number
SI7160DP
Description
Field-effect transistor
Package Condition
Tape and Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Features
• Halogen-free According to IEC 61249-2-21 Available
• Ultra-Low On-Resistance Using High Density TrenchFET® Gen II Power MOSFET Technology
•Qg Optimized
• New Low Thermal Resistance PowerPAK® Package with Low 1.07 mm Profile
• 100 percent Rg Tested
• 100 percent UIS Tested
Product Applications
• Notebook
- Logic DC/DC
Product Specifications
| Attribute | Attribute value |
| Model | Si7160DP |
| Category | Discrete Semiconductor Products |
| Transistors | |
| FETs, MOSFETs | |
| Single FETs, MOSFETs | |
| Mfr | - |
| Series | TrenchFET® |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 20A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 8.7mOhm @ 15A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 66 nC @ 10 V |
| Vgs (Max) | 卤16V |
| Input Capacitance (Ciss) (Max) @ Vds | 2970 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 5W (Ta), 27.7W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerPAK® SO-8 |
| Package / Case | PowerPAK® SO-8 |
| Base Product Number | SI7160 |
