Hot sale original electronics NSR20F30NXT5G DIODE SCHOTTKY 30V 2A 2DSN Diode 30 V 2A Surface Mount 2-DSN (1.6x.80)
Manufacturer Product Number
NSR20F30NXT5G
Description
NSR20F30NXT5G DIODE SCHOTTKY 30V 2A 2DSN Diode 30 V 2A Surface Mount 2-DSN (1.6x.80)
Package Condition
Tape & Reel (TR) Cut Tape (CT)
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| Brief Description: The NSR20F30NXT5G is a Schottky diode, designed for high-efficiency applications. It features a low leakage current and is available in a surface-mount package. Features: Low leakage current: 150μA @ 30V High efficiency: Fast recovery time of <= 500ns High current handling: 2A average rectified current High temperature operation: Maximum operating temperature of 150°C Lead-free and RoHS3 compliant Surface-mount package: 2-XDFN Application Grade: The NSR20F30NXT5G is designed for high-efficiency applications, making it suitable for use in power supplies, converters, and other high-current applications. Applications: Power supplies Converters High-current applications Efficiency-critical applications Key Specifications: Average rectified current: 2A Forward voltage: 480mV Maximum forward surge current: 28A Maximum power dissipation: 1.75W Maximum reverse voltage: 30V Maximum operating temperature: 150°C Minimum operating temperature: -40°C Package Information: Package type: 2-XDFN Package size: 0603 Packaging: Tape & Reel (TR) Mounting type: Surface-mount Terminal finish: Tin (Sn) Terminal position: Bottom Additional Information: Lifecycle status: Active Factory lead time: 17 weeks ECCN code: EAR99 HTS code: 8541.10.00.80 JESD-609 code: e3 REACH SVHC: No SVHC Radiation hardening: No |
Product Description
| Type | Description |
| ANSC PART# | ANSC-NSR20F30NXT5G |
| Category | Discrete Semiconductor Products |
| Diodes | |
| Rectifiers | |
| Single Diodes | |
| Mfr | Original |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| / | |
| Part Status | Active |
| Technology | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Current - Average Rectified (Io) | 2A |
| Voltage - Forward (Vf) (Max) @ If | 480 mV @ 2 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Current - Reverse Leakage @ Vr | 150 µA @ 30 V |
| Capacitance @ Vr, F | - |
| Mounting Type | Surface Mount |
| Package / Case | 2-XDFN |
| Supplier Device Package | 2-DSN (1.6x.80) |
| Operating Temperature - Junction | 150°C (Max) |
| Base Product Number | NSR20 |
