Hot sale original 74OL6000S Logic Output Optoisolator 15MBd Push-Pull, Totem Pole 5300Vrms 1 Channel 5kV/µs CMTI 6-SMD
Manufacturer Product Number
74OL6000S
Description
74OL6000S OPTOISOLTR 5.3KV PUSH PULL 6-SMD Optoisolators
Package Condition
Tube
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| 74OL6000S Description The 74OL6000S is a high performance, high speed optocoupler from onsemi. 74OL6000S is part of OPTOLOGIC™, which is the first family of true logic compatible optocoupled logic interface gates. 4OL6000S can be used in SMD-DIP-6 packages. 74OL6000S Features • Industry first LSTTL to TTL and LSTTL to CMOS complete logic-to-logic optocoupler • Incorporates LED drive circuitry — use as logic gate • Very high speed • Choice of buffer or inverter • Choice of TTL or CMOS compatible output up to 15 volts • Fan-out of 10 TTL loads, fan-in 1 LSTTL load • Internal noise shield — very high CMR of ±15 kV/µS • UL recognized (File #E90700) • Same noise immunity as LSTTL/TTL. 74OL6000S Applications • Transmission line interface — receiver and driver • Excellent as bridged receiver in fast LAN highways • Bus interface • Logic family interface with ground loop noise elimination • High speed AC/DC voltage sensing • Driver for power semiconductor devices • Level shifting • Replaces fast pulse transformers |
Product Description
| Type# | Description |
| ANSC PART# | ANSC-74OL6000S |
| Category | Isolators |
| Optocouplers, Optoisolators | |
| Logic Output Optoisolators | |
| Manufacturer | / |
| Series | OPTOLOGIC™ |
| Packaging | Tube |
| Part Status | Obsolete |
| Number of Channels | 1 |
| Inputs - Side 1/Side 2 | 1/0 |
| Voltage - Isolation | 5300Vrms |
| Common Mode Transient Immunity (Min) | 5kV/µs |
| Input Type | Logic |
| Output Type | Push-Pull, Totem Pole |
| Current - Output / Channel | 40 mA |
| Data Rate | 15MBd |
| Propagation Delay tpLH / tpHL (Max) | 100ns, 100ns |
| Rise / Fall Time (Typ) | 45ns, 5ns |
| Voltage - Forward (Vf) (Typ) | - |
| Current - DC Forward (If) (Max) | - |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Surface Mount |
| Package / Case | 6-SMD, Gull Wing |
| Supplier Device Package | 6-SMD |
| Base Product Number | 74OL600 |
