Hot sale Original PE42520MLBA-Z Diversity Switch 0.009MHz Min 13000MHz Max 1 Func 2.7dB Insertion
Manufacturer Product Number
PE42520MLBA-Z
Description
PE42520MLBA-Z Diversity Switch 0.009MHz Min 13000MHz Max 1 Func 2.7dB Insertion Loss-Max CMOS 3 X 3 MM GREEN QFN-16
Package Condition
Tape & Reel (TR)
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| Product Description: The PE42520MLBA-Z is a high-performance, surface-mount RF switch . This component is part of the RF/IF and RFID category, specifically designed for RF switches. With its high linearity and isolation features, it is ideal for various applications in the RF and microwave industry. Features: High linearity and isolation for improved signal quality 50 Ohm characteristic impedance for efficient signal transmission Surface-mount construction for easy integration into PCBs Operating frequency range from 0.009 MHz to 13 GHz Maximum input power of 36 dBm for reliable operation Insertion loss of 2.7 dB for minimal signal attenuation Isolation of 13 dB for effective signal separation Operating temperature range of -40°C to 85°C for versatility Applications: Primary applications: Wireless communication systems, satellite communications, and radar systems Secondary applications: Medical devices, industrial control systems, and automotive systems |
Product Description
| Type# | Description |
| ANSC PART# | ANSC - PE42520MLBA-Z |
| Package Description | Lcc16,.12sq,20 |
| Additional Feature | High Linearity And Isolation |
| Characteristic Impedance | 50 Ω |
| Construction | Component |
| Input Power-Max (CW) | 36 Dbm |
| Insertion Loss-Max | 2.7 Db |
| Isolation-Min | 13 Db |
| JESD-609 Code | e4 |
| Mounting Feature | Surface Mount |
| Number of Functions | 1 |
| Number of Terminals | 16 |
| On Time-Nom | 5.5 µS |
| Operating Frequency-Max | 13000 Mhz |
| Operating Frequency-Min | 0.009 Mhz |
| Operating Temperature-Max | 85 °C |
| Operating Temperature-Min | -40 °C |
| Package Body Material | Plastic/Epoxy |
| Package Equivalence Code | LCC16,.12SQ,20 |
| Port Termination | Absorptive |
| Power Supplies | 3.3/3.4 V |
| RF/Microwave Device Type | Spdt |
| Supply Current-Max | 0.2 Ma |
| Surface Mount | Yes |
| Technology | Cmos |
| Terminal Finish | Nickel Palladium Gold |
| VSWR-Max | 1.15 |
