Hot sale Original SN54LS245J Logic Bus Transceiver LS Series 8-Func 8-Bit True Output TTL CDIP20
Manufacturer Product Number
SN54LS245J
Description
SN54LS245J Logic Bus Transceiver LS Series 8-Func 8-Bit True Output TTL CDIP20
Package Condition
Tube
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| Product Description: The SN54LS245J is a high-performance, bidirectional transceiver IC , designed for use in a variety of applications. This 5V, 20-pin CDIP package IC features a common control type and direction control, allowing for easy integration into systems requiring bidirectional data transmission. Features: Bidirectional transceiver with common control type and direction control 5V operating supply voltage 20-pin CDIP package with a terminal pitch of 2.54mm Non-inverting polarity 3-state output characteristics Propagation delay of 40ns Turn-on delay time of 12ns High-level output current of -12mA and low-level output current of 12mA Power supply current-max (ICC) of 0.09mA Operating temperature range of -55°C to 125°C Applications: Primary applications: Industrial automation, medical devices, and automotive systems requiring bidirectional data transmission Secondary applications: Consumer electronics, telecommunications, and military/aerospace systems Alternative Parts: |
Product Description
| Type# | Description |
| ANSC PART# | ANSC - SN54LS245J |
| Part Package Code | DIP |
| Package Description | Dip, Dip20,.3 |
| Pin Count | 20 |
| Reach Compliance Code | Not Compliant |
| Additional Feature | With Direction Control |
| Control Type | Common Control |
| Count Direction | Bidirectional |
| Family | Ls |
| JESD-30 Code | R-GDIP-T20 |
| JESD-609 Code | e0 |
| Length | 24.2 Mm |
| Load Capacitance (CL) | 45 Pf |
| Logic IC Type | Bus Transceiver |
| Max I(ol) | 0.012 A |
| Number of Bits | 8 |
| Number of Functions | 8 |
| Number of Ports | 2 |
| Number of Terminals | 20 |
| Operating Temperature-Max | 125 °C |
| Operating Temperature-Min | -55 °C |
| Output Characteristics | 3-State |
| Output Polarity | TRUE |
| Package Body Material | Ceramic, Glass-Sealed |
| Package Code | DIP |
| Package Equivalence Code | DIP20,.3 |
| Package Shape | Rectangular |
| Package Style | In-Line |
| Packing Method | Tube |
| Power Supply Current-Max (ICC) | 95 Ma |
| Prop. Delay@Nom-Sup | 12 Ns |
| Propagation Delay (tpd) | 12 Ns |
| Qualification Status | Not Qualified |
| Schmitt Trigger | No |
| Seated Height-Max | 5.08 Mm |
| Supply Voltage-Max (Vsup) | 5.5 V |
| Supply Voltage-Min (Vsup) | 4.5 V |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | No |
| Technology | Ttl |
| Temperature Grade | Military |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | Through-Hole |
| Terminal Pitch | 2.54 Mm |
| Terminal Position | Dual |
| Width | 6.92 Mm |
