Hot-selling and scarce CD74ACT138M 3-LINE TO 8-LINE DECODERS/DEMULTIPLEXERS SOP16 spot stock

Product Descriptions

The ’ACT138 decoders/demultiplexers are designed for high-performance memory-decoding and data-routing applications that require very short propagation-delay times. In high-performance memory systems, these decoders can be used to minimize the effects of system decoding. When employed with high-speed memories utilizing a fast enable circuit, the delay times of these decoders and the enable time of the memory usually are less than the typical access time of the memory. This means that the effective system delay introduced by the decoders is negligible.

The conditions at the binary-select inputs and the three enable inputs select one of eight output lines. Two active-low and one active-high enable inputs reduce the need for external gates or inverters when expanding. A 24-line decoder can be implemented without external inverters, and a 32-line decoder requires only one inverter. An enable input can be used as a data input for demultiplexing applications (see Application Information).

Product Features

Inputs Are TTL-Voltage Compatible

Speed of Bipolar F, AS, and S, With Significantly Reduced Power Consumption

Designed Specifically for High-Speed Memory Decoders and Data-Transmission

Systems

Incorporate Three Enable Inputs to Simplify Cascading and/or Data Reception

Balanced Propagation Delays

±24-mA Output Drive Current

– Fanout to 15 F Devices

SCR-Latchup-Resistant CMOS Process and Circuit Design

Exceeds 2-kV ESD Protection Per MIL-STD-883, Method 3015
