Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
Hot sale Original MAX4410EUD Consumer Circuits Audio Amplifier 0.08W 2 Channel(s) 1 Func BICMOS PDSO14 4.40 MM TSSOP-14
Manufacturer Product Number
MAX4410EUD
Description
MAX4410EUD Consumer Circuits Audio Amplifier 0.08W 2 Channel(s) 1 Func BICMOS PDSO14 4.40 MM TSSOP-14
Package Condition
Original
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| General Description The MAX4410 stereo headphone driver is designed for portable equipment where board space is at a premium. The MAX4410 uses a unique, patented, DirectDrive architecture to produce a ground-referenced output from a single supply, eliminating the need for large DC-blocking capacitors, saving cost, board space, and component height. Features ♦ No Bulky DC-Blocking Capacitors Required ♦ Ground-Referenced Outputs Eliminate DC-Bias Voltages on Headphone Ground Pin ♦ No Degradation of Low-Frequency Response Due to Output Capacitors ♦ 80mW Per Channel into 16Ω ♦ Low 0.003% THD + N ♦ High PSRR (90dB at 1kHz) ♦ Integrated Click-and-Pop Suppression ♦ 1.8V to 3.6V Single-Supply Operation ♦ Low Quiescent Current ♦ Independent Left/Right, Low-Power Shutdown Controls ♦ Short-Circuit and Thermal Overload Protection ♦ ±8kV ESD-Protected Amplifier Outputs ♦ Available in Space-Saving Packages 16-Bump UCSP (2mm x 2mm x 0.6mm) 14-Pin TSSOP Applications Notebooks Cellular Phones PDAs MP3 Players Web Pads Portable Audio Equipment |
Product Description
| Type# | Description |
| ANSC PART# | ANSC- MAX4410EUD |
| Ihs Manufacturer | Original |
| Part Package Code | TSSOP |
| Package Description | 4.40 MM, TSSOP-14 |
| Pin Count | 14 |
| Bandwidth-Nom | 22 kHz |
| Consumer IC Type | AUDIO AMPLIFIER |
| Length | 5 mm |
| Moisture Sensitivity Level | 1 |
| Number of Channels | 2 |
| Number of Functions | 1 |
| Number of Terminals | 14 |
| Operating Temperature-Max | 85 °C |
| Operating Temperature-Min | -40 °C |
| Output Power-Nom | 0.08 W |
| Package Body Material | PLASTIC/EPOXY |
| Package Code | TSSOP |
| Package Equivalence Code | TSSOP14,.25 |
| Package Shape | RECTANGULAR |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH |
| Qualification Status | Not Qualified |
| Seated Height-Max | 1.1 mm |
| Supply Current-Max | 11.5 mA |
| Supply Voltage-Max (Vsup) | 3.6 V |
| Supply Voltage-Min (Vsup) | 1.8 V |
| Surface Mount | YES |
| Technology | BICMOS |
| Temperature Grade | INDUSTRIAL |
| Terminal Finish | TIN LEAD |
| Terminal Form | GULL WING |
| Terminal Pitch | 0.65 mm |
| Terminal Position | DUAL |
| Width | 4.4 mm |
Actual image of the product
