Hot-selling and scarce 74HC00D CMOS Digital Integrated Circuits Silicon Monolithic SOP14 spot stock
Manufacturer Product Number
74HC00D
Description
74HC00D CMOS Digital Integrated Circuits Silicon Monolithic SOP14 spot stock
Package Condition
Tape & Reel (TR)
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The 74HC00D is a high speed CMOS 2-INPUT NAND GATE fabricated with silicon gate C2 MOS technology.
It achieves the high speed operation similar to equivalent LSTTL while maintaining the CMOS low power dissipation.
The internal circuit is composed of 3 stages including buffer output, which provide high noise immunity and stable output.
All inputs are equipped with protection circuits against static discharge or transient excess voltage.
Product Features
(1) High speed: t pd = 6 ns (typ.) at V CC = 5 V
(2) Low power dissipation: ICC = 1.0 µA (max) Ta = 25 ℃
(3) Balanced propagation delays: tPLH ≈ tPHL
(4) Wide operating voltage range:V CC(opr) = 2.0 to 6.0 V
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-74HC00D |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | - |
| Series | 74HC |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Logic Type | NAND Gate |
| Number of Circuits | 4 |
| Number of Inputs | 2 |
| Voltage - Supply | 2V ~ 6V |
| Current - Quiescent (Max) | 1 µA |
| Current - Output High, Low | 5.2mA, 5.2mA |
| Input Logic Level - Low | 0.5V ~ 1.8V |
| Input Logic Level - High | 1.5V ~ 4.2V |
| Max Propagation Delay @ V, Max CL | 13ns @ 6V, 50pF |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 14-SOIC |
| Package / Case | 14-SOIC (0.154", 3.90mm Width) |
| Base Product Number | 74HC00 |
