Hot-selling and scarce ADUC812BSZ 12-Bit ADC with Embedded Flash MCU MQFP-52 spot stock

Product Descriptions

The ADuC812 is a fully integrated 12-bit data acquisition systemincorporating a high performance self-calibrating multichannelADC, dual DAC, and programmable 8-bit MCU (8051 instruction set compatible) on a single chip .

The programmable 8051 compatible core is supported by 8Kbytes Flash/EE program memory, 640 bytes Flash/EE datamemory, and 256 bytes data SRAM on-chip .

Additional MCU support functions include Watchdog Timer,Power Supply Monitor, and ADC DMA functions. Thirty-twoprogrammable I/O lines, I²C compatible SPI and StandardUART Serial Port I/O are provided for multiprocessor interfacesand I/O expansion .

Normal, idle, and power-down operating modes for both theMCU core and analog converters allow flexible power management schemes suited to low power applications . The part isspecified for 3 V and 5 V operation over the industrial temperature range and is available in a 52-lead, plastic quadflatpack package, and in a 56-lead, chip scale package .

Product Features

Analog I/O

8-Channel, High Accuracy 12-Bit ADC

On-Chip, 100 ppm/C Voltage Reference

High Speed 200 kSPS

DMA Controller for High Speed ADC-to-RAM Capture

2 12-Bit Voltage Output DACs

On-Chip Temperature Sensor Function

Memory

8K Bytes On-Chip Flash/EE Program Memory

640 Bytes On-Chip Flash/EE Data Memory

256 Bytes On-Chip Data RAM

16M Bytes External Data Address Space

64K Bytes External Program Address Space

8051 Compatible Core

12 MHz Nominal Operation (16 MHz Max)

3 16-Bit Timer/Counters

High Current Drive Capability—Port 3

9 Interrupt Sources, 2 Priority Levels

Power

Specified for 3 V and 5 V Operation

Normal, Idle, and Power-Down Modes

On-Chip Peripherals

UART and SPI® Serial I/O

2-Wire (400 kHz I2C® Compatible) Serial I/O

Watchdog Timer

Power Supply Monitor

Product Applications

Intelligent Sensors Calibration and Conditioning

Battery-Powered Systems (Portable PCs, Instruments,

Monitors)

Transient Capture Systems

DAS and Communications Systems

Control Loop Monitors (Optical Networks/Base Stations)
