Hot-selling and scarce SN74LVC541APWR OCTAL BUFFERS/DRIVERS WITH 3-STATE OUTPUT TSSOP20 spot stock

Product Descriptions

The SN54LVC541A octal buffer/driver is designed for 2.7-V to 3.6-V VCC operation, and the SN74LVC541A octal buffer/driver is designed for 1.65-V to 3.6-V VCC operation.

The ’LVC541A devices are ideal for driving bus lines or buffering memory address registers.

These devices feature inputs and outputs on opposite sides of the package to facilitate printed circuit board layout.

The 3-state control gate is a 2-input AND gate with active-low inputs so that, if either output enable (OE1 or OE2) input is high, all eight outputs are in the high-impedance state.

Inputs can be driven from either 3.3-V or 5-V devices. This feature allows the use of these devices as translators in a mixed 3.3-V/5-V system environment.

These devices are fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the devices when they are powered down.

To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

Product Features

 Operate From 1.65 V to 3.6 V

 Inputs Accept Voltages to 5.5 V

 Max tpd of 5.1 ns at 3.3 V

 Typical VOLP (Output Ground Bounce) <0.8 V at VCC = 3.3 V, TA = 25°C

 Typical VOHV (Output VOH Undershoot) >2 V at VCC = 3.3 V, TA = 25°C

 Support Mixed-Mode Signal Operation on All Ports (5-V Input/Output Voltage With 3.3-V VCC)

 Ioff Supports Partial-Power-Down Mode Operation

 Latch-Up Performance Exceeds 250 mA Per JESD 17

 ESD Protection Exceeds JESD 22

− 2000-V Human-Body Model (A114-A)

− 200-V Machine Model (A115-A)

− 1000-V Charged-Device Model (C101)
