Hot-selling and scarce EE80C196KC20 COMMERCIAL/EXPRESS CHMOS MICROCONTROLLER PLCC spot stock

Product Descriptions

The 80C196KC 16-bit microcontroller is a high performance member of the MCS 96 microcontroller family The 80C196KC is an enhanced 80C196KB device with 488 bytes RAM  16 and 20 MHz operation and an optional  16  Kbytes of  ROMOTPROM  Intel’s CHMOS  III process provides a  high performance processor along with low power consumption

The 87C196KC is an 80C196KC with 16 Kbytes on-chip OTPROM The 83C196KC is an 80C196KC with 16 Kbytes factory programmed ROM In this document the 80C196KC will refer to all products unless otherwise stated

Four high-speed capture inputs are provided to record times when events occur Six high-speed outputs are available for pulse or waveform generation The high-speed output can also generate four software timers or start an AD conversion Events can be based on the timer or updown counter

With the commercial (standard) temperature option operational characteristics are guaranteed over the temperature range of 0C to  a 70C With the extended (Express) temperature range option operational characteristics are guaranteed over the temperature range of b 40C to a 85C Unless otherwise noted the specifications are the same for both options

See the Packaging information for extended temperature designators.

Product Features

Y   16 and 20 MHz Available

Y    488 Byte Register RAM

Y    Register-to-Register Architecture

Y    28 Interrupt Sources16 Vectors

Y    Peripheral Transaction Server

Y    14 ms 16 x 16 Multiply (20 MHz)

Y    24 ms 3216 Divide (20 MHz)

Y    Powerdown and Idle Modes

Y    Five 8-Bit IO Ports

Y    16-Bit Watchdog Timer

Y    Extended Temperature Available

Y    Dynamically Configurable 8-Bit or 16-Bit Buswidth

Y    Full Duplex Serial Port

Y    High Speed IO Subsystem

Y    16-Bit Timer

Y    16-Bit UpDown Counter with Capture

Y    3 Pulse-Width-Modulated Outputs

Y    Four 16-Bit Software Timers

Y    8- or 10-Bit AD Converter with SampleHold

Y    HOLDHLDA Bus Protocol

Y    OTPROM One-Time Programmable Version

Product Photos

For more product information, please download the PDF

WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
