Hot sale Original ACS712ELCTR-05B-T Current Sensors Hall Effect, Open Loop Sensor 1-Channel Bidirectional 5V DC~80kHz
Manufacturer Product Number
ACS712ELCTR-05B-T
Description
Original ACS712ELCTR-05B-T SENSOR CURRENT HALL 5A AC/DC Current Sensor 5A 1 Channel Hall Effect, Open Loop Bidirectional 8-SOIC (0.154", 3.90mm Width)
Package Condition
Tape & Reel (TR) Cut Tape (CT)
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Overview
Current sensors are housed in 8-SOIC (0.154, 3.90mm Width) packages to ensure their safety. In order to prevent damage to the devices, these current sensors are packaged in Tape & Reel (TR). Current sensors should supply no more current than 13mA. Current sensors have terminations of 8. Current sensors have 8 pins. When they are operated, the current sensors can provide 5V voltage. The current sensors can provide a voltage of 5V when they are in operation. Electronic parts with 8 pins are available. Current sensors should produce a 10mA output.
Product Features
Moisture Sensitivity Level: 2 (1 Year)
Operating Temperature: -40°C~85°C
1 Channels
Mounting Type: Surface Mount
Sensor Type: Hall Effect, Open Loop
Supply Voltage: 5V
Frequency: DC~80kHz
Sensing Current: 5A
8-SOIC (0.154, 3.90mm Width) Package
Product Applications
Proving Switch
DC and AC power monitoring
Frequency, Voltage, and Solar Inverters
Static converters for DC motor drives
Electrical drives
Battery supplied application
Overcurrent protection
DC motor drives
Uninterruptable Power Supllies (UPS)
Continuity
Product Description
|
Type |
Description |
|---|---|
|
ANSC PART# |
ANSC - ACS712ELCTR-05B-T |
|
Category |
Sensors, Transducers Current Sensors |
|
Mfr |
/ |
|
Series |
- |
|
Packaging |
Tape & Reel (TR) Cut Tape (CT) |
|
Part Status |
Not For New Designs |
|
For Measuring |
AC/DC |
|
Sensor Type |
Hall Effect, Open Loop |
|
Current - Sensing |
5A |
|
Number of Channels |
1 |
|
Output |
Ratiometric, Voltage |
|
Sensitivity |
185mV/A |
|
Frequency |
DC ~ 80kHz |
|
Linearity |
±1.5% |
|
Accuracy |
±1.5% |
|
Voltage - Supply |
5V |
|
Response Time |
5µs |
|
Current - Supply (Max) |
13mA |
|
Operating Temperature |
-40°C ~ 85°C |
|
Polarization |
Bidirectional |
|
Mounting Type |
Surface Mount |
|
Package / Case |
8-SOIC (0.154", 3.90mm Width) |
|
Supplier Device Package |
8-SOIC |
|
Base Product Number |
ACS712 |
Actual image of the product
Product datasheet
For more information, please download
