Hot sale Original MPX2300DT1 SENSOR 5.8PSID .003006V Pressure Sensor 5.8PSI (40kPa) Differential 4-SSIP Module
Manufacturer Product Number
MPX2300DT1
Description
MPX2300DT1 Pressure Sensor 5.8PSI (40kPa) Differential 4-SSIP Module
Package Condition
Tape & Reel (TR) Cut Tape (CT)
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
Quality and Reliability—Overview
A Major Objective of the Production Cycle From rigid incoming inspection of piece parts and materials, to stringent outgoing quality verification, the Motorola assembly and process flow is encompassed by an elaborate system of test and inspection stations; stations to ensure a
step-by-step adherence to prescribed procedure. This produces the high level of quality for which Motorola is known. . . from start to finish.
As illustrated in the process flow overview, every major manufacturing step is followed by an appropriate in-process quality inspection to insure product conformance to specification. In addition, Statistical Process Control (S.P.C.) techniques are utilized on all critical processes to insure
processing equipment is capable of producing the product to the target specification while minimizing the variability. Quality control in wafer processing, assembly, and final test impart Motorola sensor products with a level of reliability that easily exceeds almost all industrial, consumer, and military requirements.
Product Description
|
Type |
Description |
|---|---|
|
Category |
Sensors, Transducers Pressure Sensors, Transducers |
|
Manufacturer |
/ |
|
Series |
MPX2300 |
|
Packaging |
Tape & Reel (TR) Cut Tape (CT) |
|
Part Status |
Active |
|
Applications |
Board Mount |
|
Pressure Type |
Differential |
|
Operating Pressure |
5.8PSI (40kPa) |
|
Output Type |
Wheatstone Bridge |
|
Output |
0 mV ~ 3.006 mV (6V) |
|
Accuracy |
±1.5% |
|
Voltage - Supply |
6V ~ 10V |
|
Port Size |
- |
|
Port Style |
No Port |
|
Features |
Temperature Compensated |
|
Termination Style |
PC Pin |
|
Maximum Pressure |
125PSI (861.84kPa) |
|
Operating Temperature |
15°C ~ 40°C |
|
Mounting Type |
Through Hole |
|
Package / Case |
4-SSIP Module |
|
Supplier Device Package |
- |
|
Base Product Number |
MPX2300 |
Actual image of the product
