Hot-selling and scarce TS5V330DBQR QUAD SPDT WIDE-BANDWIDTH VIDEO SWITCH WITH LOW ON-STATE RESISTANCE SSOP16 spot stock
Manufacturer Product Number
TS5V330DBQR
Description
TS5V330DBQR QUAD SPDT WIDE-BANDWIDTH VIDEO SWITCH WITH LOW ON-STATE RESISTANCE SSOP16 spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Features
• Low Differential Gain and Phase (DG = 0.64%, DP = 0.1 Degrees Typ)
• Wide Bandwidth (BW = 300 MHz Min)
• Low Crosstalk (XTALK = –63 dB Typ)
• Low Power Consumption (ICC = 3 µA Max)
• Bidirectional Data Flow With Near-Zero Propagation Delay
• Low ON-State Resistance (ron = 3 Ω Typ)
• VCC Operating Range From 4.5 V to 5.5 V
• Ioff Supports Partial-Power-Down Mode Operation
• Data and Control Inputs Provide Undershoot Clamp Diode
• Control Inputs Can Be Driven by TTL or 5-V/3.3-V CMOS Outputs
• Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
• ESD Performance Tested Per JESD 22
– 1000-V Charged-Device Model (C101)
• Suitable for Both RGB and Composite-Video Switching
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-TS5V330DBQR |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches - Special Purpose | |
| Manufacturer | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Obsolete |
| Applications | Video |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Switch Circuit | SPDT |
| Number of Channels | 4 |
| On-State Resistance (Max) | 10Ohm |
| Voltage - Supply, Single (V+) | 4V ~ 5.5V |
| -3db Bandwidth | 300MHz (Min) |
| Features | Bi-Directional, RGB |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SSOP |
| Base Product Number | TS5V330 |
