BOM distribution service electronic components 1N5819HW-7-F 1.0A surface mounted Schottky barrier rectifier
Manufacturer Product Number
1N5819HW-7-F
Description
1N5819HW-7-F Diode 40V 1A Surface Mount SOD-123
Package Condition
Tape & Reel (TR) Cut Tape (CT)
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
Description
The 1N5819HW-7-F is a surface mount Rectifier Diode with moulded plastic case. Suitable for low voltage,
high frequency inverters. The rectifier diode have a high current capability and low forward voltage drop.
Features
High Surge Capability
Low Power Loss and High Efficiency
Guard Ring Die Construction for Transient Protection
Moulded Plastic
Matte Tin-plated Leads
Cathode Band Polarity
Halogen-free
Application
Automotive, Power Management
Product Description
|
Type |
Description |
|---|---|
| PART# | 1N5819HW-7-F |
|
Category |
Discrete Semiconductor Products Diodes Rectifiers Single Diodes |
|
Mfr |
/ |
|
Series |
- |
|
Packaging |
Tape & Reel (TR) Cut Tape (CT) |
|
Part Status |
Active |
|
Technology |
Schottky |
|
Voltage - DC Reverse (Vr) (Max) |
40 V |
|
Current - Average Rectified (Io) |
1A |
|
Voltage - Forward (Vf) (Max) @ If |
450 mV @ 1 A |
|
Speed |
Fast Recovery =< 500ns, > 200mA (Io) |
|
Current - Reverse Leakage @ Vr |
1 mA @ 40 V |
|
Capacitance @ Vr, F |
60pF @ 4V, 1MHz |
|
Mounting Type |
Surface Mount |
|
Package / Case |
SOD-123 |
|
Supplier Device Package |
SOD-123 |
|
Operating Temperature - Junction |
-65°C ~ 125°C |
|
Base Product Number |
1N5819 |
Actual image of the product
