Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
2018 New High Sensitivity MG811 CO2 Carbon Gas Concentration Sensor
Manufacturer
Manufacturer Product Number
mg811
Description
2018 New High Sensitivity MG811 CO2 Carbon Gas Concentration Sensor
Package Condition
Original
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| Product Details The MG811 CO2 sensor has excellent sensitivity and selectivity for CO2 and is minimally affected by temperature and humidity fluctuations. It also offers excellent stability and reproducibility. It is primarily used in air quality control systems, fermentation process control, and greenhouse CO2 concentration detection structures and test circuits. Sensor Features Excellent sensitivity and selectivity for CO2 Minimally affected by temperature and humidity fluctuations Excellent stability and reproducibility Main Applications Air quality control systems Fermentation process control Greenhouse CO2 concentration detection |
Product Description
| Type# | Description |
| Product Model | MG811 |
| Product Type | Solid Electrolyte Gas Sensor |
| Standard Package | Metal Package |
| Detected Gas | Carbon Dioxide |
| Detected Concentration | 350-10000ppm CO2 |
| Heating Voltage (VH) | 6.0±0.1V AC |
| Load Resistance (RL) | Adjustable |
| Heating Resistance (RH) | 35Ω±3Ω (Room Temperature) |
| Heating Power Consumption (PH) | Approximately 1200mW |
| Temperature, Humidity | 20°C±2°C; 65%±5%RH |
Product Photos
