Hot BOM distribution service electronic components WIDE BAND AND FLAT GAIN AMPLIFIER UPC1688G-T1-A Professional supply Original

Manufacturer
Original
Manufacturer Product Number
UPC1688G-T1-A
Description

UPC1688G-T1-A Wide Band Low Power Amplifier 1100MHz Max MINIMOLD 4 PIN

Package Condition
Original
Datasheet
UPC1688G-T1-A
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser. All intellectual property rights of products on our website belong to the original factory! (In addition to ANSC's own customized products)

Product Details

DESCRIPTION

The µPC1688G is a silicon monolithic integrated circuit especially designed as a flat gain and wide band amplifier covering HF through UHF band.

FEATURES
• Flat gain: ∆GP = ±1 dBTYP. @ f = 0.1 to 0.7 GHz
• Frequency response : 1.1 GHzTYP. @ 3dB band width
• Power gain : 21 dBTYP. @ 0.5 GHz
• Supply voltage : 5 V ± 0.5 V
• 4 pin mini mold package

Product Description

Type# Description
PART# UPC1688G-T1-A
Ihs Manufacturer /
Package Description MINIMOLD, 4 PIN
Characteristic Impedance 50 Ω
Construction COMPONENT
Gain 18 dB
Input Power-Max (CW) 10 dBm
Operating Frequency-Max 1100 MHz
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
RF/Microwave Device Type WIDE BAND LOW POWER
Terminal Finish Tin/Bismuth (Sn/Bi)

Actual image of the product

UPC1688G-T1-A
