Hot-selling and scarce CD4017BCN Decade Counter/Divider with 10 Decoded Outputs DIP16 spot stock

Product Descriptions

The CD4017BC is a 5-stage divide-by-10 Johnson counter with 10 decoded outputs and a carry out bit.

The CD4022BC is a 4-stage divide-by-8 Johnson counter with 8 decoded outputs and a carry-out bit.

These counters are cleared to their zero count by a logical“1” on their reset line. These counters are advanced on the positive edge of the clock signal when the clock enable signal is in the logical“0” state.

The configuration of the CD4017BC and CD4022BC permits medium speed operation and assures a hazard free counting  sequence. The  10/8 decoded  outputs are  normally in the logical“0” state and go to the logical“1” state only  at their  respective  time  slot.  Each  decoded  output remains  high for  1 full clock cycle. The carry-out signal completes a full cycle for every 10/8 clock input cycles and is used as a ripple carry signal to any succeeding stages.

Product Features

■ Wide supply voltage range:   3 .0V to 15V

■ High noise immunity:   0.45 V DD (typ.)

■ Low power   Fan out of 2 driving 74L TTL compatibility:   or 1 driving 74LS

■ Medium speed operation:   5 .0 MHz (typ.) with 10V VDD

■ Low power:    10 µW (typ.)

■ Fully static operation

Product Applications

•  Automotive

•   Instrumentation

•   Medical electronics

•  Alarm systems

•   Industrial electronics

•   Remote metering

Product Specification

Product Photos

For more product information, please download the PDF
