Hot-selling and scarce AT91SAM9260-QU Thumb Microcontrollers IC QFP spot stock

Product Features

•  Incorporates the ARM926EJ-S™ ARM® Thumb® Processor

– DSP Instruction Extensions, ARM Jazelle® Technology for Java® Acceleration

– 8-KByte Data Cache, 8-KByte Instruction Cache, Write Buffer

– 200 MIPS at 180 MHz

– Memory Management Unit

– EmbeddedICE™, Debug Communication Channel Support

•  Additional Embedded Memories

– One 32 KByte Internal ROM, Single-cycle Access At Maximum Matrix Speed

– Two 4 KByte Internal SRAM, Single-cycle Access At Maximum Matrix Speed

•  External Bus Interface (EBI)

– Supports SDRAM, Static Memory, ECC-enabled NAND Flash and CompactFlash®

•  USB 2.0 Full Speed (12 Mbits per second) Device Port

– On-chip Transceiver, 2,432-byte Configurable Integrated DPRAM

•  USB 2.0 Full Speed (12 Mbits per second) Host Single Port in the 208-lead PQFP Package and Double Port in 217-ball LFBGA Package

– Single or Dual On-chip Transceivers

– Integrated FIFOs and Dedicated DMA Channels

•  Ethernet MAC 10/100 Base T

– Media Independent Interface or Reduced Media Independent Interface

– 28-byte FIFOs and Dedicated DMA Channels for Receive and Transmit

•  Image Sensor Interface

– ITU-R BT. 601/656 External Interface, Programmable Frame Capture Rate

– 12-bit Data Interface for Support of High Sensibility Sensors

– SAV and EAV Synchronization, Preview Path with Scaler, YCbCr Format

•  Bus Matrix

– Six 32-bit-layer Matrix

– Boot Mode Select Option, Remap Command

•  Fully-featured System Controller, including

– Reset Controller, Shutdown Controller

– Four 32-bit Battery Backup Registers for a Total of 16 Bytes

– Clock Generator and Power Management Controller

– Advanced Interrupt Controller and Debug Unit

– Periodic Interval Timer, Watchdog Timer and Real-time Timer

•  Reset Controller (RSTC)

– Based on a Power-on Reset Cell, Reset Source Identification and Reset Output Control

•  Clock Generator (CKGR)

– Selectable 32,768 Hz Low-power Oscillator or Internal Low Power RC Oscillator on Battery Backup Power Supply, Providing a Permanent Slow Clock

– 3 to 20 MHz On-chip Oscillator, One up to 240 MHz PLL and One up to 130 MHz PLL

•  Power Management Controller (PMC)

– Very Slow Clock Operating Mode, Software Programmable Power Optimization Capabilities

– Two Programmable External Clock Signals

•  Advanced Interrupt Controller (AIC)

– Individually Maskable, Eight-level Priority, Vectored Interrupt Sources

– Three External Interrupt Sources and One Fast Interrupt Source, Spurious Interrupt Protected

Product Photos

For more product information, please download the PDF

WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
