Spot sales of MAX1614EUA+T High-Side, n-Channel MOSFET Switch Driver MSOP8

Product Descriptions

The MAX1614 drives high-side, n-channel power MOSFETs to provide battery power-switching functions in portable equipment. The n-channel power MOSFETs typically have one-third the on-resistance of p-channel MOSFETs of similar size and cost. An internal micropower regulator and charge pump generate the high-side drive output voltage, while requiring no external components.

The MAX1614 also features a 1.5 percent-accurate low-battery comparator that can be used to indicate a low-battery condition, provide an early power-fail warning to the system microprocessor, or disconnect the battery from the load, preventing deep discharge and battery damage. An internal latch allows for pushbutton on/off control with very low current consumption. Off-mode current consumption is only 6μA while normal operation requires less than 25μA. The MAX1614 is available in the space-saving μMAX® package that occupies about 60 percent less space than a standard 8-pin SO.

Product Features

● Integration Provides a Simple-to-Use Solution

• Requires No External Components

• Internal On/Off Latch Facilitates Pushbutton Control

• 1.5 percent Accurate Low-Battery Detector Protects Battery and Data Stored in Memory

• Controlled Turn-On for Low Inrush Current

● Low Power Consumption Extends Battery Life

• 25µA (max) Quiescent Current

• 6µA (max) Shutdown Current

● µMAX Package is 60% Smaller Than Typical 8-Pin SO Solution

● Supports Typical Requirements of Portable, BatteryPowered Designs

• 5V to 26V Input Voltage Range

• Drives Single or Back-to-Back MOSFETs

Product Applications

● ​Notebook Computers

● Portable Equipment

● Hand-Held Instruments

● Battery Packs

Product Specification

Product Photos

For more product information, please download the PDF
