Hot-selling and scarce BQ24261MYFFT Power-Path Management and USB-OTG Support DSBGA spot stock

Product Descriptions

The bq24260/bq24261/bq24261M/bq24262 is a highly integrated single-cell Li-Ion battery charger and system power path management device that supports operation from either a USB port or wall adapter supply. The power-path feature allows the bq24260/1/1M/2 to power the system from a high efficiency DC-DC converter while simultaneously and independently charging the battery. The power path also permits the battery to supplement the system current requirements when the adapter cannot. Many features are programmable using the I2C interface.

To support USB OTG applications, the bq24260/1/1M/2 is configurable to boost the battery voltage to 5 V and supply up to 1 A at the input. The battery is charged with three phases: precharge, constant current, and constant voltage. Therma regulation prevents the die temperature from exceeding 125°C. Additionally, a JEITA-compatible battery pack thermistor monitoring input (TS) is included to prevent the battery from charging outside of its safe temperature range.

Product Features

• Charge Time Optimizer (Enhanced CC/CV Transition) for Faster Charging

• Integrated FETs for up to 3-A Charge Rate at 5 percent Accuracy and 93 percent Peak Efficiency

• Boost Capability to Supply 5 V at 1 A at IN for USB OTG Supply

• Integrated 17-mΩ Power-Path MOSFET and Optional BGATE Control to Maximize Battery Life and Instantly Start up From a Deeply Discharged Battery or No Battery

• 30-V Input Rating With Overvoltage Protection Supports 5-V USB 2.0/3.0 and 12-V USB Power Delivery (bq24261/1M)

• Small Solution Size In a 2.4-mm × 2.4-mm 36-Pin WCSP or 4-mm × 4-mm 24-Pin QFN Package

– Total Charging Solution Can be 50 mm2 or Less With WCSP

• Safe and Accurate Battery-Management Functions Programmed Using I2C Interface

– Charge Voltage, Current, Termination Threshold, Input Current Limit, VIN_DPM Threshold

– Voltage-Based, JEITA-Compatible NTC Monitoring Input

– Thermal Regulation Protection for Input Current Control

– Thermal Shutdown and Protection

Product Applications

• Smart Phones and Tablets

• Handheld Products

• Power Banks and External Battery Packs

• Small Power Tools

• Portable Media Players and Gaming

Product Specification

Product Photos

For more product information, please download the PDF
