Hot-selling and scarce BZX84C2V7-7-F 350mW SURFACE MOUNT ZENER DIODE SOT23 spot stock

Manufacturer Product Number

BZX84C2V7-7-F

Description

BZX84C2V7-7-F 350mW SURFACE MOUNT ZENER DIODE SOT23 spot stock

Package Condition

TaPe & Reel

Datasheet

BZX84C2V7-7-F

Product Details
Reviews

We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser. All intellectual property rights of products on our website belong to the original factory! (In addition to ANSC's own customized products)

Product Data

· Case: SOT-23

· Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0

· Moisture Sensitivity: Level 1 per J-STD-020C

· Terminals: Solderable per MIL-STD-202, Method 208

· Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe).

· Polarity: See Diagram

· Weight: 0.008 grams (approximate)

Product Features

· Planar Die Construction

· 350mW Power Dissipation

· Zener Voltages from 2.4V - 39V

· Ideally Suited for Automated Assembly Processes

· Lead Free/RoHS Compliant (Note 4)

· Qualified to AEC-Q101 Standards for High Reliability

Product Specification

Attribute	Attribute value
ANSM-Part#	ANSM-BZX84C2V7-7-F
Category	Discrete Semiconductor Products
	Diodes
	Zener
	Single Zener Diodes
Mfr	-
Packaging	Tape & Reel (TR)
	Cut Tape (CT)
	Digi-Reel®
Part Status	Active
Voltage - Zener (Nom) (Vz)	2.7 V
Tolerance	±7%
Power - Max	300 mW
Impedance (Max) (Zzt)	100 Ohms
Current - Reverse Leakage @ Vr	20 µA @ 1 V
Voltage - Forward (Vf) (Max) @ If	900 mV @ 10 mA
Operating Temperature	-65°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	TO-236-3, SC-59, SOT-23-3
Supplier Device Package	SOT-23-3
Base Product Number	BZX84
