Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
Hot-selling and scarce CR75NP-100KC POWER INDUCTORS SMD spot stock
Manufacturer Product Number
CR75NP-100KC
Description
CR75NP-100KC POWER INDUCTORS SMD spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
・8.1×7.3mm Max.(L×W), 5.5mm Max. Height.
・Inductance Range: 1.2～470μH
・Rated current range: 0.34～6.0A
・In addition to the standard versions of inductors shown here, custom inductors are available to meet your exact requirements.
Product Features
・Magnetically unshielded construction.
・Ideally used in A/V equipment, LCD TV,DSC/DVC, Game Machine, DVC, HDD, Notebook PC, etc as DC-DC Converter inductors.
・RoHS Compliance
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-CR75NP-100KC |
| Category | Inductors, Coils, Chokes |
| Fixed Inductors | |
| Mfr | - |
| cms-filter-header-series | CR75 |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 10 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 2.3 A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 70mOhm Max |
| Frequency - Self Resonant | 28MHz |
| Operating Temperature | -40°C ~ 100°C |
| Inductance Frequency - Test | 2.52 MHz |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
| Height - Seated (Max) | 0.217" (5.50mm) |
Product Photos
、
For more product information, please download the PDF
