Hot sale original electronics SKM75GDL123D Standard IGBT Modules IGBT six pack with chopper standard 1200(V) 75(A)
Manufacturer Product Number
SKM75GDL123D
Description
SKM75GDL123D Insulated Gate Bipolar Transistor 75A I(C) 1200V V(BR)CES N-Channel CASE SEMITRANS 18 PIN
Package Condition
Original
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| Section 6: SEMITRANS® IGBT Modules; New Range 1995/96 3rd Version: Low Inductance, lower VCEsat, soft and fast CAL diodes 1); Preliminary Data 4) 1) CAL = Controlled Axial Lifetime Technology 2) 1600 V and 1700 V IGBTs have Visol = 4 kVrms/1 min 3) 1700 V types will replace 1600 V types in 1996 4) All data apply to one single IGBT element 5) Option enlarged diode, and suffix "1" 6) Option collector sense, add suffix "S" = case 60 |
Product Description
| Type# | Description |
| ANSC PART# | ANSC- SKM75GDL123D |
| Manufacturer | / |
| Part Package | DO-204 |
| Package Description | CASE D73, SEMITRANS 6, 18 PIN |
| Pin Count | 2 |
| Case Connection | ISOLATED |
| Collector Current-Max (IC) | 75 A |
| Collector-Emitter Voltage-Max | 1200 V |
| Configuration | COMPLEX |
| Gate-Emitter Voltage-Max | 20 V |
| Number of Elements | 7 |
| Number of Terminals | 18 |
| Operating Temperature-Max | 150 °C |
| Package Body Material | UNSPECIFIED |
| Package Shape | RECTANGULAR |
| Package Style | FLANGE MOUNT |
| Polarity/Channel Type | N-CHANNEL |
| Power Dissipation-Max (Abs) | 350 W |
| Qualification Status | Not Qualified |
| Reference Standard | UL RECOGNIZED |
| Surface Mount | NO |
| Terminal Finish | TIN SILVER |
| Terminal Form | UNSPECIFIED |
| Terminal Position | UPPER |
| Transistor Application | POWER CONTROL |
| Transistor Element Material | SILICON |
| Turn-off Time-Nom (toff) | 450 ns |
| Turn-on Time-Nom (ton) | 100 ns |
| VCEsat-Max | 3 V |
Actual image of the product
Product datasheet
For more information, please download
Payment&Transportation
Official Certificate&Certificate
Standard packaging
Multiple product supply
Welcome to visit our company
Warehouse Real Shot
