Hot-selling and scarce JAN4N48 Hi-Reliability Optically Coupled Isolator CAN6 spot stock

Manufacturer Product Number

JAN4N48

Description

JAN4N48 Hi-Reliability Optically Coupled Isolator CAN6 spot stock

Package Condition

Bulk

Datasheet

JAN4N48

Product Details
Reviews

We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser. All intellectual property rights of products on our website belong to the original factory! (In addition to ANSC's own customized products)

Product Descriptions

Each isolator in this series consists of an infrared emitting diode and a NPN silicon phototransistor, which are mounted in a hermetically sealed TO-78 package. Devices are designed for military and/or harsh environments. The suffix letter“A”denotes the collector is electrically isolated from the case.

Product Features

• TO-78 hermetically sealed package

• High current transfer ratio

• 1 kV electrical isolation

• Base contact provided for conventional transistor biasing

• JAN, JANTX and JANTXV devices processed to MIL-PRF-19500

• Patent No. 4124860

Product Applications

• High-voltage isolation between input and output

• Electrical isolation in dirty environments

• Industrial equipment

• Medical equipment

• Office equipment

Product Specification

Attribute	Attribute value
ANSM-Part#	ANSM-JAN4N48
Category	Isolators
	Optocouplers, Optoisolators
	Transistor, Photovoltaic Output Optoisolators
Manufacturer	-
Packaging	Bulk
Part Status	Obsolete
Number of Channels	1
Voltage - Isolation	1000VDC
Current Transfer Ratio (Min)	100% @ 1mA
Current Transfer Ratio (Max)	500% @ 1mA
Rise / Fall Time (Typ)	20µs, 20µs (Max)
Input Type	DC
Output Type	Transistor with Base
Voltage - Output (Max)	40V
Current - Output / Channel	50mA
Voltage - Forward (Vf) (Typ)	1.5V (Max)
Current - DC Forward (If) (Max)	40 mA
Vce Saturation (Max)	300mV
Operating Temperature	-55°C ~ 125°C
Mounting Type	Through Hole
Package / Case	TO-78-6 Metal Can
Supplier Device Package	TO-78-6
