Hot-selling and scarce APTGT75SK120TG Buck chopper Fast Trench + Field Stop IGBT Power Module DIP spot stock

Manufacturer Product Number

APTGT75SK120TG

Description

APTGT75SK120TG Buck chopper Fast Trench + Field Stop IGBT Power Module DIP spot stock

Package Condition

Tube

Datasheet

APTGT75SK120TG

Product Details
Reviews

We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser. All intellectual property rights of products on our website belong to the original factory! (In addition to ANSC's own customized products)

Product Benefits

• Stable temperature behavior

• Very rugged

• Solderable terminals for easy PCB mounting

• Direct mounting to heatsink (isolated package)

• Low junction to case thermal resistance

• Easy paralleling due to positive TC of VCEsat

• Low profile

• RoHS Compliant

Product Features

• Fast Trench +Field Stop IGBT®Technology

- Low voltage drop

- Low tail current

- Switching frequency up to 20 kHz

- Soft recovery parallel diodes

- Low diode VF

- Low leakage current

- Avalanche energy rated

- RBSOA and SCSOA rated

• Kelvin emitter for easy drive

• Very low stray inductance

- Symmetrical design

- Lead frames for power connections

• High level of integration

• Internal thermistor for temperature monitoring

Product Applications

• AC and DC motor control

• Switched Mode Power Supplies

Product Specification

Attribute	Attribute value
ANSM-Part#	ANSM-APTGT75SK120TG
Category	Discrete Semiconductor Products
	Transistors
	IGBTs
	IGBT Modules
Manufacturer	-
Packaging	Bulk
Part Status	Active
IGBT Type	Trench Field Stop
Configuration	Single
Voltage - Collector Emitter Breakdown (Max)	1200 V
Current - Collector (Ic) (Max)	110 A
Power - Max	357 W
Vce(on) (Max) @ Vge, Ic	2.1V @ 15V, 75A
Current - Collector Cutoff (Max)	250 µA
Input Capacitance (Cies) @ Vce	5.34 nF @ 25 V
Input	Standard
NTC Thermistor	Yes
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Chassis Mount
Package / Case	SP4
Supplier Device Package	SP4
Base Product Number	APTGT75
