Image shown is a representation only.
Exact specifications should be obtained from the product data sheet.
Hot-selling and scarce 74F541SCX Octal Buffer/Line Driver with 3-STATE Outputs SOP20 spot stock
Manufacturer Product Number
74F541SCX
Description
74F541SCX Octal Buffer/Line Driver with 3-STATE Outputs SOP20 spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The 74F540 and 74F541 are similar in function to the 74F240 and 74F244 respectively, except that the inputs and outputs are on opposite sides of the package (see Connection Diagrams). This pinout arrangement makes these devices especially useful as output ports for microprocessors, allowing ease of layout and greater PC board density
Product Features
■ 3-STATE outputs drive bus lines
■ Inputs and outputs opposite side of package, allowing easier interface to microprocessors
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-74F541SCX |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Buffers, Drivers, Receivers, Transceivers | |
| Manufacturer | - |
| Series | 74F |
| Packaging | Tape & Reel (TR) |
| Part Status | Obsolete |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 1 |
| Number of Bits per Element | 8 |
| Output Type | 3-State |
| Current - Output High, Low | 3mA, 64mA |
| Voltage - Supply | 4.5V ~ 5.5V |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) |
| Supplier Device Package | 20-SOIC |
| Base Product Number | 74F541 |
Product Photos
For more product information, please download the PDF
