Smart Highside Power Switch Electronic components BOM Integrated circuit IC BTS6143D

Product Features

• Reverse battery protection by self turn on of power MOSFET

• Short circuit protection with latch

• Current limitation • Overload protection

• Thermal shutdown with restart

• Overvoltage protection (including load dump)

• Loss of ground protection

• Loss of Vbb protection (with external diode for charged inductive loads)

• Very low standby current

• Fast demagnetisation of inductive loads

•Electrostatic discharge (ESD) protection

• Optimized static electromagnetic compatibility (EMC)

Diagnostic Function

• Proportional load current sense (with defined fault signal in case of overload operation, overtemperature shutdown and/or short circuit shutdown)

Product Application

• Power switch with current sense diagnostic feedback for 12V and 24 V DC grounded loads

• All types of resistive, inductive and capacitive loads

• Replaces electromechanical relays, fuses and discrete circuits

Product Description

N channel vertical power FET with charge pump, current controlled input and diagnostic feedback with load current sense, integrated in Smart SIPMOS chip on chip technology. Providing embedded protective functions.
