Hot-selling and scarce NC7SZ125P5X TinyLogic UHS Buffer with Three-State Output SC70-5 spot stock
Manufacturer Product Number
NC7SZ125P5X
Description
NC7SZ125P5X TinyLogic UHS Buffer with Three-State Output SC70-5 spot stock
Package Condition
Tape & Reel (TR)
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The NC7SZ125 is a single buffer with three−state output Ultra−High Speed (UHS) of TinyLogic. The device is fabricated with advanced CMOS technology to achieve ultra high speed with high output drive while maintaining low static power dissipation over a very broad V CC operating range. The device is specified to operate over the 1.65 V to 5.5 V range. The inputs and output are high impedance above ground when V CC is 0 V. Inputs tolerate voltages up to 5.5 V independent of V CC operating voltage. The output tolerates voltages above V CC when in the 3−STATE condition.
Product Features
Ultra−High Speed:tPD =2.6 ns (Typical)into 50 pF at 5 V V CC
High Output Drive: 24 mA at 3 V V CC
Broad V CC Operating Range: 1.65 V to 5.5 V
Matches Performance of LCX when Operated at 3.3 V V CC
Power Down High−Impedance Inputs /Outputs
Over−Voltage Tolerance Inputs Facilitate 5 V to 3 V Translation
Proprietary Noise /EMI Reduction Circuitry
Ultra−Small MicroPak Packages
Space−Saving SOT23−5,SC−74A and SC−88A Packages
These Devices are Pb−Free,Halogen Free/BFR Free and are RoHS Compliant
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-NC7SZ125P5X |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Buffers, Drivers, Receivers, Transceivers | |
| Manufacturer | - |
| Series | 7SZ |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Logic Type | Buffer, Non-Inverting |
| Number of Elements | 1 |
| Number of Bits per Element | 1 |
| Output Type | 3-State |
| Current - Output High, Low | 32mA, 32mA |
| Voltage - Supply | 1.65V ~ 5.5V |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Supplier Device Package | SC-70-5 |
| Base Product Number | NC7SZ125 |
Product Photos
For more product information, please download the PDF
Other Products In The same category:
NC7SZ125P5X TinyLogic UHS Buffer with Three-State Output SC70-5 spot stock
No stock
Can ship immediately
