Hot-selling and scarce NC7SV08L6X TinyLogic® ULP-A 2-Input AND Gate SOT-363 spot stock
Manufacturer Product Number
NC7SV08L6X
Description
NC7SV08L6X TinyLogic® ULP-A 2-Input AND Gate SOT-363 spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The NC7SV08 is a single 2-Input AND Gate from Fairchild’s Ultra Low Power-A (ULP-A) series of TinyLogic. ULP-A is ideal for applications that require extreme high speed, high drive and low power. This product is designed for a wide low voltage operating range (0.9V to 3.6V) VCC and applications that require more drive and speed than the TinyLogic ULP series, but still offer best in class low power operation.
The NC7SV08 is uniquely designed for optimized power and speed, and is fabricated with an advanced CMOS technology to achieve high-speed operation while maintaining low CMOS power dissipation.
Product Features
■ 0.9V to 3.6V VCC supply operation
■ 3.6V overvoltage tolerant I/O’s at VCC from 0.9V to 3.6V
■ Extremely High Speed tPD
1.0 ns typ for 2.7V to 3.6V VCC
1.2 ns typ for 2.3V to 2.7V VCC
2.0 ns typ for 1.65V to 1.95V VCC
3.2 ns typ for 1.4V to 1.6V VCC
6.0 ns typ for 1.1V to 1.3V VCC
13 ns typ for 0.9V VCC
■ Power-Off high impedance inputs and outputs
■ High Static Drive (IOH/IOL)
±24 mA @ 3.00V VCC
±18 mA @ 2.30V VCC
±6 mA @ 1.65V VCC
±4 mA @ 1.4V VCC
±2 mA @ 1.1V VCC
±0.1 mA @ 0.9V VCC
■ Uses patented Quiet Series noise/EMI reduction circuitry
■ Ultra small MicroPak leadfree package
■ Ultra low dynamic power
Product Specifications
| Attribute | Attribute value |
| ANSM-Part# | ANSM-NC7SV08L6X |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | - |
| Series | 7SV |
| Packaging | Bulk |
| Part Status | Active |
| Logic Type | AND Gate |
| Number of Circuits | 1 |
| Number of Inputs | 2 |
| Voltage - Supply | 0.9V ~ 3.6V |
| Current - Quiescent (Max) | 900 nA |
| Current - Output High, Low | 24mA, 24mA |
| Input Logic Level - Low | 0.7V ~ 0.8V |
| Input Logic Level - High | 1.6V ~ 2V |
| Max Propagation Delay @ V, Max CL | 2.3ns @ 3V, 30pF |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 6-MicroPak |
| Package / Case | 6-UFDFN |
| Base Product Number | 7SV08 |
Product Photos
For more product information, please download the PDF
WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
