RGB color sensor development board module TCS34725

Product Description

TCS34725 color recognition sensor module

●TCS34725 color sensor chip provides digital return values ​​for red, green, blue (RGB) and bright light sensing;

●Color-sensitive photodiode integrated chip and localized infrared light-blocking filter minimize the infrared spectrum component of the incident light, making color management more accurate;

●High sensitivity, wide dynamic range and infrared light-blocking filter make TCS34725 an ideal color-sensitive component solution for changing light conditions and passing through attenuation materials;

●TCS34725 color sensor has a wide range of applications, including RGB LED backlight control, solid-state lighting, health products, industrial process control and medical diagnostic equipment;

Product Parameters

1. Working voltage: 3.3~5V

2. Detection distance: 3~10mm

3. Communication mode: IIC

Product pin definition and description

1. VIN positive power supply

2. GND negative power supply

3. 3V3 3.3V output

4. SCL clock signal

5. SDA data signal

6. INT interrupt output, low level is valid

7. LED controls the LED light near the sensor, the LED light is on when the high level signal or floating, and the LED light is off when the low level signal

 Actual image of the product
