PCA9685 16 channel 12 bit Fm+I2C bus PWM controller servo control module
Manufacturer
Manufacturer Product Number
PCA9685
Description
PCA9685 16 channel controller servo control module
Package Condition
Bulk
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Parameter
Using IIC communication;
The module logic and servo are powered separately, with a logic power supply voltage of 3-5V and a maximum servo power supply voltage of 6V;
Onboard logic power indicator light;
Introduce 16 sets of 3-pin servo motor interfaces to facilitate the connection of 16 motors in the same service at once;
Cascade design, convenient for cascading the next 16 servo modules;
All PWM output lines have a 220 ohm resistor for signal output protection
Product Descriptions
This servo driver board uses PCA9685 chip and is a 16 channel 12 bit PwM servo driver. It can drive 16 servos through I2C with 12 pins. Not only that, up to 62 driver boards can be cascaded through cascading, which can drive a total of 992 servos.
