Spot sales of SN74LS14N HEX SCHMITT-TRIGGER INVERTERS DIP-14
Manufacturer Product Number
SN74LS14N
Description
SN74LS14N HEX SCHMITT-TRIGGER INVERTERS DIP-14
Package Condition
Tube
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
Each circuit in SNx414 and SNx4LS14 functions as an inverter. However, because of the Schmitt-Trigger action, they have different input threshold levels for positive-going (VT+) and negative-going (VT– ) signals.
These circuits are temperature compensated and can be triggered from the slowest of input ramps and still give clean, jitter-free output signals.
Product Features
• Operation From Very Slow Edges
• Improved Line-Receiving Characteristics
• High Noise Immunity
Product Applications
• HVAC Gateways
• Residential Ductless Air Conditioning Outdoor Units
• Robotic Controls
• Industrial Stepper Motors
• Power Meter and Power Analyzers
• Digital Input Modules for Factory Automation
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-SN74LS14N |
| Category | Integrated Circuits (ICs) |
| Logic | |
| Gates and Inverters | |
| Mfr | Texas Instruments |
| Series | 74LS |
| Packaging | Tube |
| Part Status | Active |
| Logic Type | Inverter |
| Number of Circuits | 6 |
| Number of Inputs | 1 |
| Features | Schmitt Trigger |
| Voltage - Supply | 4.75V ~ 5.25V |
| Current - Output High, Low | 400µA, 8mA |
| Input Logic Level - Low | 0.5V |
| Input Logic Level - High | 1.9V |
| Max Propagation Delay @ V, Max CL | 22ns @ 5V, 15pF |
| Operating Temperature | 0°C ~ 70°C |
| Mounting Type | Through Hole |
| Supplier Device Package | 14-PDIP |
| Package / Case | 14-DIP (0.300", 7.62mm) |
| Base Product Number | 74LS14 |
Product Photos
For more product information, please download the PDF
