Hot-selling and scarce HSMR-C110 High Performance Chip LED spot stock

Product Descriptions

These small chip-type LEDs utilize high efficient and high brightness InGaN material to deliver competitively priced high performance blue and green. These 520 nm green and 470 nm blue are unique hues which provide color differentiation to a product.

These ChipLEDs come in either top emitting packages(HSMx-C130,C150,C170,C177,C190,C191,C197), in side emitting packages (HSMx-C110,C120)or in a reverse mount package  (C265). The side emitting package is especially suitable for LCD backlighting application. The top emitting packages, with their wide viewing angle,are suitable for direct backlighting application or being used with light pipes. In order to facilitate pick and place operation, these ChipLEDs are shipped in tape and reel with 4000 units per reel for HSMx-C120, C130, C170, C177, C190, C191 and C197 packages, and 3000 units per reel for HSMxC110, C150 and C265 packages. All packages are compatible with IR soldering and binned by both color and intensity.

Product Features

• High brightness

• Small size

• Industrial standard footprint

• Diffused optics

• Top emitting or right angle emitting

• Compatible with IR soldering

• Compatible for use with light piping

• Available in 8 mm tape on 7" diameter reel

• Reel sealed in zip locked moisture barrier bags

Product Applications

• LCD backlighting

• Push button backlighting

• Front panel indicator

• Symbol indicator

• Microdisplays

• Small message panel signage

Product Specifications

Product Photos

For more product information, please download the PDF
