Hot-selling and scarce HSMA-C110 High Performance Chip LED spot stock

Product Descriptions

These chip-type LEDs utilize Aluminum Indium Gallium Phosphide  (AlInGaP)  material technology. The AlInGaP material has a very high luminous efficiency, capable of producing high light output over a wide range of drive currents.The available colors in this surface mount series are 592 nm Amber, 605 nm Orange, 626/631 nm Red for AS AlInGaP.

All packages are binned by both color and intensity, except for red color.

These ChipLEDs come either in two top emitting packages (HSMx-C170/C190/C191/C150) or in a side emitting package (HSMx-C110).The right angle ChipLEDs are suitable for applications such as LCD backlighting. The top emitting ChipLEDs with wide viewing angle are suitable for light piping and direct backlighting of    keypads and panels.  In order to facilitate  pick and  place operation, these ChipLEDs are shipped in tape and reel, with 4000 units per reel for HSMx-C170/C190/C191 and 3000 units per reel for HSMx-C110/C150

These packages are compatible with IR soldering process.

Product Features

High brightness AlInGaP material

Small size

Industry standard footprint

Diffused optics

Top emitting or right angle emitting

Available in 3 colors (red, orange, amber)

Compatible with IR soldering

Available in 8 mm tape on  7" diameter reel

Reel sealed in zip locked moisture barrier bags

Product Applications

LCD backlighting

Push button backlighting

Front panel indicator

Symbol indicator

Microdisplays

Small message panel signage

Product Specifications

Product Photos

For more product information, please download the PDF
