TS3USB221RSER High-Speed USB 2.0 1:2 Multiplexer or Demultiplexer Switch with Single Enable QFN10 spot stock

Product Descriptions

The TS3USB221 is a high-bandwidth switch specially designed  for  the  switching  of  high-speed  USB  2.0 signals in handset and consumer applications, such as   cell   phones,   digital   cameras,   and   notebooks with  hubs or controllers with  limited  USB  I/Os. The wide bandwidth (1GHz) of this switch allows signals to  pass  with  minimum  edge  and  phase  distortion. The  device  multiplexes  differential  outputs  from  a USB   host   device   to   one   of   two   corresponding outputs.  The  switch  is  bidirectional  and  offers  little or  no  attenuation  of the  high-speed  signals  at  the outputs. The TS3USB221 is designed for low bit-to-bit skew  and  high  channel  to  channel  noise  isolation. The  TS3USB221  is  also  compatible  with  various standards, such as high-speed USB 2.0 (480Mbps).

Product Features

•   V CC operation from 2.3V and 3.6V

•   VI/O accepts signals up to 5.5V

•    1.8V compatible control-pin inputs

•    Low-power mode when OE is disabled (1μA)

•    RON = 6Ω maximum

•   ΔrON = 0.2Ω typical

•    CIO(ON) = 6pf maximum

•    Low power consumption (30μA maximum)

•    ESD > 2000V Human-Body Model (HBM)

•    High bandwidth (1GHz typical)

​

Product Applications

•    Routes signals for USB 1.0, 1.1, and 2.0

•    Mobile industry processor interface (MIPI™) signal routing

•    MHL 1.0
