Hot-selling and scarce TS3A5018DBQR 10-Ω Quad SPDT Analog Switch SSOP16 spot stock
Manufacturer Product Number
TS3A5018DBQR
Description
TS3A5018DBQR 10-Ω Quad SPDT Analog Switch SSOP16 spot stock
Package Condition
TaPe & Reel
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The TS3A5018 device is a quad single-pole doublethrow (SPDT) analog switch that is designed tooperate from 1.8 V to 3.6 V . This device can handledigital and analog signals, and signals up to V+ canbe transmitted in either direction .
Product Features
• Low ON-State Resistance (10 Ω)
• Low Charge Injection
• Excellent ON-State Resistance Matching
• Low Total Harmonic Distortion (THD)
• 1. 8-V to 3. 6-V Single-Supply Operation
• Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II
• ESD Performance Tested Per JESD 22
– 2000-V Human-Body Mode (A114-B, Class II)
– 1000-V Charged-Device Model (C101)
Product Applications
• Sample-and-Hold Circuits
• Battery-Powered Equipment
• Audio and Video Signal Routing
• Communication Circuits
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-TS3A5018DBQR |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Analog Switches, Multiplexers, Demultiplexers | |
| Manufacturer | - |
| Packaging | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Part Status | Active |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Circuits | 4 |
| On-State Resistance (Max) | 10Ohm |
| Channel-to-Channel Matching(ΔRon) | 300mOhm |
| Voltage - Supply, Single (V+) | 1.65V ~ 3.6V |
| Switch Time (Ton, Toff) (Max) | 8ns, 6.5ns |
| -3db Bandwidth | 300MHz |
| Charge Injection | 2pC |
| Channel Capacitance (CS(off), CD(off)) | 4.5pF, 9pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Crosstalk | -48dB @ 10MHz |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SSOP |
| Base Product Number | TS3A5018 |
