Hot-selling and scarce ADUM1201BRZ Dual-Channel Digital Isolators SOP8 spot stock

Product Descriptions

The ADuM1200/ADuM12011 are dual-channel digital isolatorsbased on the Analog Devices, Inc ., iCoupler® technology. Combining high speed CMOS and monolithic transformer technologies,these isolation components provide outstanding performance characteristics superior to alternatives, such as optocouplers .

By avoiding the use of LEDs and photodiodes, iCoupler devicesremove the design difficulties commonly associated with opto-couplers .

Product Features

►  Narrow body, RoHS-compliant, SOIC 8-lead package

►  Low power operation

►  5 V operation

►  1.1 mA per channel maximum at 0 Mbps to 2 Mbps

►  3.7 mA per channel maximum at 10 Mbps

►  8.2 mA per channel maximum at 25 Mbps

►  3 V operation

►  0.8 mA per channel maximum at 0 Mbps to 2 Mbps

► 2.2 mA per channel maximum at 10 Mbps

► 4.8 mA per channel maximum at 25 Mbps

►  Bidirectional communication

►  3 V/5 V level translation

►  High temperature operation: 125°C

►  High data rate: dc to 25 Mbps (NRZ)

►  Precise timing characteristics

►  3 ns maximum pulse width distortion

►  3 ns maximum channel-to-channel matching

►  High common-mode transient immunity: >25 kV/µs

►  Safety and regulatory approvals

►  UL 1577

► V ISO = 2500 V RMS for 1 minute

►  IEC/EN/CSA 62368-1

►  IEC/CSA 61010-1

►  CQC GB4943 .1

►  DIN EN IEC 60747-17 (VDE 0884-17)

► V IORM = 560 V PEAK

► AEC-Q100 qualified for automotive applications

Product Applications

►  Size-critical multichannel isolation

►  SPI interface/data converter isolation

►  RS-232/RS-422/RS-485 transceiver isolation

►  Digital field bus isolation

►  Hybrid electric vehicles, battery monitor, and motor drive

Product Specification

Product Photos

For more product information, please download the PDF
