Hot-selling and scarce AD9929BBCZ CCD Signal Processor with Precision Timing Generator BGA64 spot stock

Product Descriptions

The AD9929 is a highly integrated CCD signal processor fordigital still camera and digital video camera applications .Itincludes a complete analog front end with A/D conversion,combined with a full-function,programmable timing generator.The AD9929 also includes horizontal and vertical clock drivers,which allow direct connection to the CCD image sensor.

The AD9929 is specified at pixel rates of up to 36 MHz.Theanalog front end includes black level clamping,a CDS,a VGA,and a 12-bit A/D converter.The timing generator provides allthe necessary CCD clocks: RG-clock,H-clocks,V-clocks,sensorgate pulses,a substrate clock,and a substrate bias pulse .Operation is programmed using a 3-wire serial interface .

The AD9929 is packaged in a 64-lead CSPBGA .It is specifiedover an operating temperature range of −25°C to +85°C .

Product Features

36 MSPS correlated double sampler (CDS)

12-bit 36 MHz A/D converter

On-chip vertical driver for CCD image sensor

On-chip horizontal driver for CCD image sensor

6 dB to 40 dB variable gain amplifier (VGA)

Black level clamp with variable level control

Complete on-chip timing generator

Precision Timing core with 0.58 ns resolution

2-phase H-clock modes

4-phase vertical transfer clocks

Electronic and mechanical shutter modes

On-chip sync generator with external sync option

64-lead, plastic ball, 9 × 9 grid array Pb-free package

Product Applications

Digital still cameras

Digital video camcorders
