Hot-selling and scarce ADV7520NKBBCZ-80 Low-Power HDMI/DVI Transmitter BGA spot stock
Manufacturer Product Number
ADV7520NKBBCZ-80
Description
ADV7520NKBBCZ-80 Low-Power HDMI/DVI Transmitter BGA spot stock
Package Condition
Tray
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The ADV7520NK is an 80 MHz, high definition multimediainterface (HDMI™) v.1.3 transmitter with consumer electroniccontrol (CEC). It supports HDTV formats up to 720p and 1080iand computer graphic resolutions up to XGA (1024 × 768 @75 Hz). With the inclusion of HDCP, the ADV7520NK allowsthe secure transmission of protected content,as specified by theHDCP 1.3 protocol.
The ADV7520NK supports both S/PDIF and 8-channel I2S audio.Its high fidelity, 8-channel I2S can transmit either stereo or 7.1surround audio at 192 kHz.The S/PDIF can carry stereo linearpulse-code modulation (LPCM) audio or compressed audio,including Dolby®Digital and DTS®.
Product Features
General
Low power HDMI/DVI transmitter ideal for portable
applications
CEC controller and buffer reduce system overhead
Compatible with HDMI v.1.3, DVI v.1.0, and HDCP 1.3
Supports xvYCC functionality
Single 1.8 V power supply
Video/audio inputs accept logic levels from 1.8 V to 3.3 V
Digital video
80 MHz operation supports all HDTV resolutions from
480i to 1080i
Programmable 2-way color space converter
Supports RGB,YCbCr, and DDR
Supports ITU656-based embedded syncs
Automatic input video format timing detection (CEA-861D)
Digital audio
Supports standard S/PDIF for stereo LPCM or compressed
audio up to 192 kHz
8-channel, uncompressed LPCM I2S audio up to 192 kHz
Special features for easy system design
On-chip MPU with I2C master to perform HDCP operations
and EDID reading operations
5 V tolerant I2C and HPD I/Os, no extra device needed
No audio master clock needed for supporting S/PDIF and I2S
On-chip MPU reports HDMI events through interrupts and
registers
Product Applications
Digital video cameras
Digital still cameras
Personal media players
Cellular handsets
DVD players and recorders
Digital set-top boxes
A/V receivers
HDMI repeater/splitter
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-ADV7520NKBBCZ-80 |
| Category | Integrated Circuits (ICs) |
| Linear | |
| Video Processing | |
| Manufacturer | - |
| Packaging | Tray |
| Part Status | Obsolete |
| Function | Transmitter |
| Applications | Consumer Video |
| Standards | CEA-861B, DVI 1.0, HDCP 1.3, HDMI 1.3, ITU656 |
| Control Interface | I2C |
| Voltage - Supply | 1.8V ~ 3V |
| Mounting Type | Surface Mount |
| Package / Case | 76-LFBGA, CSPBGA |
| Supplier Device Package | 76-CSPBGA (6x6) |
| Base Product Number | ADV7520 |
