Hot-selling and scarce AD9949KCPZ 12-Bit CCD Signal Processor with Precision Timing Core LFCSP-48 spot stock
Manufacturer Product Number
AD9949KCPZ
Description
AD9949KCPZ 12-Bit CCD Signal Processor with Precision Timing Core LFCSP-48 spot stock
Package Condition
TRAY
Datasheet
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Descriptions
The AD9949 is a highly integrated CCD signal processor fordigital still camera applications. Specified at pixel rates of up to36 MHz, the AD9949 consists of a complete analog front endwith A/D conversion, combined with a programmable timingdriver. The Precision Timing core allows adjustment of highspeed clocks with < 600 ps resolution .
The analog front end includes black level clamping, CDS,PxGA, VGA, and a 36 MSPS, 12-bit ADC. The timing driverprovides the high speed CCD clock drivers for RG and H1 toH4. Operation is programmed using a 3-wire serial interface .
Packaged in a space-saving, 40-lead LFCSP package, theAD9949 is specified over an operating temperature range of−20°C to +85°C .
Product Features
New AD9949A supports CCD line length > 4096 pixels
Correlated double sampler (CDS)
0 dB to 18 dB pixel gain amplifier (PxGA®)
6 dB to 42 dB 10-bit variable gain amplifier (VGA)
12-bit, 36 MSPS analog-to-digital converter (ADC)
Black level clamp with variable level control
Complete on-chip timing driver
Precision Timing™ core with < 600 ps resolution
On-chip 3 V horizontal and RG drivers
40-lead LFCSP package
Product Applications
Digital still cameras
High speed digital imaging applications
Product Specification
| Attribute | Attribute value |
| ANSM-Part# | ANSM-AD9949KCPZ |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Sensor and Detector Interfaces | |
| Manufacturer | - |
| Packaging | Tray |
| Part Status | Discontinued at DigiKey |
| DigiKey Programmable | Not Verified |
| Type | CCD Signal Processor, 12-Bit |
| Input Type | Logic |
| Output Type | Logic |
| Operating Temperature | -20°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 40-VFQFN Exposed Pad, CSP |
| Supplier Device Package | 40-LFCSP (6x6) |
| Base Product Number | AD9949 |
