Hot-selling and scarce LP2982IM5X-3.3 50-mA Micropower Ultra-Low-Dropout LDO in SOT-23 Package spot stock

Product Descriptions

The LP2982 is a 50-mA, fixed-output voltage LDO designed to provide ultra-low dropout and lower noise in battery-powered applications.

Using an optimized vertically integrated PNP (VIP) process, the LP2982 delivers unequaled performance in all    specifications  critical    to  battery-powered designs:

Dropout Voltage: Typically 120 mV at 50 mA load, and 7 mV at 1 mA load.

Ground Pin Current: Typically 375 μA at 50 mA load, and 80 μA at 1 mA load.

Sleep Mode: Less than 1-μA quiescent current when ON/OFF pin is pulled low.

Precision Output:   1% tolerance output   voltages available (A grade) .

Low Noise: By adding an external  bypass capacitor, output noise can be reduced to 30 μV (typical) .

Product Features

•   2. 1-V to 16-V Input Voltage

•   Ultra-Low-Dropout Voltage

•   Ensured 50-mA Output Current

•   Typical Dropout Voltage 180 mV at 80 mA

•   Requires Minimum External Components

•   < 1 μA Quiescent Current When Shut Down

•   Low Ground Pin Current at All Loads

•   Output Voltage Accuracy 1% (A Grade)

•   High Peak Current Capability (150 mA Typical)

•   Wide Supply Voltage Range (16 V Maximum)

•   Low ZOUT 0.3 ΩTypical (10 Hz to 1 MHz)

•   Overtemperature and Overcurrent Protection

•   −40°C to +125°C Junction Temperature Range

Product Applications

•   Cellular Phones

•   Palmtop and Laptop Computers

•   Personal Digital Assistants (PDA)

•   Camcorders, Personal Stereos, Cameras

Product Specifications

Product Photos

For more product information, please download the PDF
