You can contact me for the best price Logic MC14585BCP ICs Logic Comparators 4-Bit CMOS Magnitude Hot sale original electronics
Manufacturer Product Number
MC14585BCP
Description
Logic MC14585BCP ICs Logic Comparators 4-Bit CMOS Magnitude Hot sale original electronics
Package Condition
tube
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Details
| 4-Bit Magnitude Comparator The MC14585B4–Bit Magnitude Comparator is constructed with comple mentaryMOS (CMOS) enhancement mode devices. The circuit has eight comparinginputs (A3, B3, A2, B2, A1, B1, A0, B0), three cascading inputs (A < B, A = B, and A > B), andthree outputs (A < B, A = B, and A > B). This devicecompares two4–bit words (A and B) and determines whether they are“less than”, “equal to”, or “greater than” by ahigh level on the appropriate output.For words greater than 4–bits, unitscan be cascaded by connecting outputs (A > B), (A< B), and (A = B) to the corresponding inputs of the next significantcomparator. Inputs (A < B), (A= B), and (A > B) on the least significant(first) comparator are connected toa low, a high, and a low, respectively. Applicationsincludelogic in CPU’s, correction and/or detection of instrumentation conditions, comparator in testers, converters, and controls. • Diode Protection on All Inputs • Expandable • Applicable to Binary or 8421–BCD Code • Supply Voltage Range = 3.0 Vdc to 18 Vdc • Capable of Driving Two Low–power TTL Loads or One Low–power Schottky TTL Load over the Rated Temperature Range • Can be Cascaded – See Fig. 3 |
Product Description
| Type# | Description |
| ANSC PART# | ANSC - MC14585BCP |
| Part Package | DIP |
| Package Description | Dip, Dip16,.3 |
| Pin Count | 16 |
| Factory Lead Time | 4 Weeks |
| Family | 4000/14000/40000 |
| JESD-30 Code | R-PDIP-T16 |
| JESD-609 Code | e0 |
| Length | 19.175 Mm |
| Load Capacitance (CL) | 50 Pf |
| Logic IC Type | Magnitude Comparator |
| Number of Bits | 4 |
| Number of Functions | 1 |
| Number of Terminals | 16 |
| Operating Temperature-Max | 125 °C |
| Operating Temperature-Min | -55 °C |
| Output Polarity | Inverted |
| Package Body Material | Plastic/Epoxy |
| Package Code | DIP |
| Package Equivalence Code | DIP16,.3 |
| Package Shape | Rectangular |
| Package Style | In-Line |
| Packing Method | Rail |
| Peak Reflow Temperature (Cel) | 235 |
| Propagation Delay (tpd) | 860 Ns |
| Qualification Status | Not Qualified |
| Seated Height-Max | 4.44 Mm |
| Supply Voltage-Max (Vsup) | 18 V |
| Supply Voltage-Min (Vsup) | 3 V |
| Supply Voltage-Nom (Vsup) | 5 V |
| Surface Mount | No |
| Technology | Cmos |
| Temperature Grade | Military |
| Terminal Finish | Tin/Lead (Sn/Pb) |
| Terminal Form | Through-Hole |
| Terminal Pitch | 2.54 Mm |
| Terminal Position | Dual |
| Time@Peak Reflow Temperature-Max (s) | 30 |
| Width | 7.62 Mm |
