Hot-selling and scarce CD4069UBF CMOS Hex Inverter CDIP14 spot stock

Product Descriptions

The CD4069UB device consist of six CMOS inverter circuits. These devices are intended for all generalpurpose inverter applications where the mediumpower TTL-drive and logic-level-conversion capabilities of circuits such as the CD4009 and CD4049 hex inverter and buffers are not required.

Product Features

• Standardized symmetrical output characteristics

• Medium speed operation: tPHL, tPLH = 30 ns at 10V (Typical)

• 100% Tested for quiescent current at 20 V

• Maximum input current of 1 µA at 18 V over full package-temperature range, 100 nA at 18 V and 25°C

• Meets all requirements of JEDEC tentative standard No. 13B, Standard Specifications for Description of B Series CMOS Devices

Product Applications

• Logic inversion

• Pulse shaping

• Oscillators

• High-input-impedance amplifiers

Product Photos

For more product information, please download the PDF

WhenCE is HIGH (deselected),the device assumes a standby mode at which the power dissipation can be reduced down to250 µW (typical) with CMOS input levels.
