Hot sale Original BSS138N H6327 MOSFET N-Ch 60V 230mA SOT-23-3
Manufacturer Product Number
BSS138N H6327
Description
BSS138N H6327 MOSFET N-Ch 60V 230mA SOT-23-3
Package Condition
Tape & Reel (TR)
We are just Spot traders, Stockists, Sraders, PCBA&BOM service providers,Purchaser.
All intellectual property rights of products on our website belong to the original factory!
(In addition to ANSC's own customized products)
Product Description
| Product attributes | Attribute value |
| PART# | BSS138N H6327 |
| Manufacturer: | / |
| Product Types: | MOSFET |
| Technology: | Yes |
| Installation style: | SMD/SMT |
| Package/Cabinet: | TODAY-23-3 |
| Transistor polarity: | N-Channel |
| Number of channels: | 1 Channel |
| VDS-Leakage Source Pole Breakdown Voltage: | 60 V |
| ID-Continuous Drain Current: | 230 mA |
| RDS On-Drain On-Resistors: | 2.2 Ohms |
| Vgs - Gate-Source Voltage: | - 20 V, 20 V |
| Vgs TH-gate source electrode threshold voltage: | 1 V |
| Qg-Gate Charge: | 1 nC |
| Minimum Operating Temperature: | - 55 C |
| Maximum Operating Temperature: | + 150 C |
| PD - Power Dissipation: | 360 mW |
| Channel Mode: | Enhancement |
| Eligibility: | AEC-Q100 |
| Package: | Reel |
| Package: | Cut Tape |
| Package: | MouseReel |
| Trademarks: | Infineon Technologies |
| Configuration: | Single |
| Descent time: | 8.2 ns |
| Forward transconductor - minimum: | 100 mS |
| Height: | 1.1 mm |
| Length: | 2.9 mm |
| Products: | MOSFET Small Signals |
| Product Type: | MOSFETs |
| Rise time: | 3 ns |
| Series: | BSS138 |
| Subcategories: | Transistors |
| Transistor Type: | 1 N-Channel |
| Typical shutdown delay time: | 6.7 ns |
| Typical Turn-on Delay Time: | 2.3 ns |
| Width: | 1.3 mm |
| Unit Weight: | 8 mg |
Actual image of the product
